Gael Langevin posted a new activity comment 3 years, 8 months ago
Hello, That is not a happy story. Dead PC… G-CODE is related to each printer settings. The slicer will generate a G-CODE according to a specific printer model size, I doubt getting someone else G-CODE, will work properly on your printer. Unless you remove the specifications in it prior printing..
Ah okay I understand. I add it to the collection.
Sheet metal fixed with 2 components glue.
The Mega Arduino use the Nervo Board as a shield. I tried various headset with noise cancellation, another interesting fact I noticed, is that microphone noise cancellation removes the beginning and the end of the sentence. This is okay if you say for example: “How do you do today”, the “Ho” and “ay” will be removed. But when you say only a…[Read more]
Interesting! You might want to head over to MyRobotLab.org to chat with the developpers. Some builders are also playing around with ESP and I think there might be a service implemented for it in MRL. ESP32 connected to MRL
si certo ma il tempo e poco, lo farò sicuramente quando l’interfaccia web funziona per poter condividere il codice e scambiarci informazioni.
yes of course but time and little, I will certainly do it when the web interface works to share the code and exchange information.
Hello, You only need to purchase some static foam for the current pressure sensors. Static foam
MyRobotLab Manticore version is not implemented with configuration file to make usage of the finger sensors. You will need to add your own python codes in the Custom.py file. See this thread in the…[Read more]
Gael, I found your video regarding this foam and copper sheets on youTube! Thank you! Marcia
Question: Are the Copper sheets metal or tape or what kind of material is used here? Thanks!
Gael,
What gauge or MM thickness is this copper metal sheet?
Thanks!
I used some 0.20mm copper. But the thickness of the copper doesn’t impact on the sensor itself.
Thanks for sharing! What is the main difference with the official one? I use the official one with the JX-HV2060MG on my latest InMoov, and it fits, that’s why I am asking. 🙂
This one has a better fitting, tried the official one first but the potentiometer pin is not centered in a nice way. With the new design it’s perfect.. If you like, you can add the design to your inMoov collection 😉
1- If you’re questionning about the dedicated Nano for the NeoPixel ring, I do not add a shield, I just route the wires and solder them to the board. If you want you can make a connection wire for to disasemble.
2-You do not need wifi Arduino for the robot, if you follow the standard assembly. Your PC will have wifi and that is the only…[Read more]
Do the MEGA or UNO boards need shields? Making a connection wire is a great idea.
I see I should have thought through the Wi-Fi decision a little more.
I have used Plantronics for 25 years while traveling as a consultant. Their devices are great. I never had an issue and never gave any thought to it not working well in quiet. I will check…[Read more]
Hello, this one: https://store.arduino.cc/arduino-nano
Hello, No it doesn’t fit within InMoov, although there should be plenty of space to do that in the legs for example. But I never designed a casing for the power supply because, I believe the battery should be what is carried around if the robot is autonomous.
Lors de l’installation de MyRobotLab, les composants openCV necessaires sont installés dans le dossier C:\Myrobotlab\myrobotlab.1.0.2693.9\libraries\jar
Thanks for the comment. Did you get to use the Italian chatbot for conversation in MyRobotLab?
Hello. No I haven’t used my robot lab software yet. As a movement test I used a 24-channel Pololu card (PWM generator). Creating pre-set and stored movements first. when it is complete then I will address the SOFTWARE speech.
Well sometimes it takes me weeks before I do a comment. But what you are trying to achieve is trully interesting!
Super cool! I am waiting to see the next video
Thanks Gael, it looks like you never get tired to comment on user actions. Feedback hasn’t been great so far (or rather is non-existent) but your note will motivate me to continue.
Hello, I am always glad to hear teachers using InMoov as a project for their students!
Hello, La seule procédure, c’est d’installer MyRobotLab via START_INMOOV.bat en suivant le tutoriel ici: how-to-start-myrobotlab Et ensuite d’activer OpenCV dans le fichier de configuration comme ceci: 1-Editez C:/myrobotlab/myrobotlab.1.2693.9/InMoov/config/service_D_OpenCV.config 2-…[Read more]
Dois-je supposer que OpenCv fait déjà partie de l’installation de RobotLab? ..ou dois-je installer OpenCV sur mon ordinateur avant? …c’est peut-être une question stupide…enfin… 🙂
Je suis déjà assez avancé avec RobotLab car je converse avec mon robot depuis quelques mois déjà!
Hey! A piece of the documentary. I personnaly think it’s more interesting to see the whole documentary with it’s full context. Thanks for saving this part.
Hello, This sounds very promising! I bet with ROS you should be able to benefit of already made database for neural network processing. If you want to discuss more about that, I suggest you head over to the developpers of MyRobotLab, I am sure you will have great help and clues to find together.
I always had a doubt about Anakin being the father of Luke…
😅😁
Hey great progress Michael! That little stand is handy for working on the head. 🙂 If you have any questions regarding the Nervo Board, just ask…
Welcome Gerd Fetzer
Thanks for posting this serie of pictures. You have done a good job.
Welcome to 057 !
Grazie per il benvenuto. Ma devo rigraziare te per questo progetto veramente magnifico. Ho avuto modo di portare 057 ad una fiera dell’ elettronica a Gonzaga in Italia con un gruppo di Arduino lab e (anche se non completo) ha avuto un successo strepitoso….. e tutto questo grazie a te . I miei complimenti x tutte le spiegazioni della…[Read more]
Hello I recently made a video which might help you to understand. You should be closer to 90 degrees with the potentiometer angulation.
Good video and interesting for builders! Thanks for sharing.
Use a 16 Neopixel ring from Adafruit or elsewhere.
Neopixel diagram & configuration
Hi Gael, WHICH Nano board should I purchase for this application? There seem to be more than one to choose from at Arduino.
Thanks! Marcia
Hello and welcome. I have never played with the esp8266 so I wouldn’t be able to comment on that. Let us know how this goes if you keep up with your idea.
Ciao piacere Gael grazie del benvenuto, ho qualche esperienza con l’esp8266 più lo scopro e più mi piace :). Per fare delle prove di movimento dell’avambraccio sinistro che ho finito di stampare ( a dire il vero ho stampato anche il bicipide la spalla sinistra e ora sto stampando il torace , appena capisco come fare l’upload delle foto le p…[Read more]
Pour ma part, j’utilise de l’ABS car facile à souder avec de l’acétone. L’ABS se ponce et lime beaucoup plus facilement que le PLA. Mais il y a beaucoup de personne qui préfère le PLA. Dans ce cas, utilisez un PLA avec une certaine souplesse pour éviter que certaines parties se cassent comme du verre.
How cool is that!
All thanks to you sir…. With your amazing design 3D parts, it gets easy to take attraction of people in any events.
Very good, Thanks for posting. I hope InMoov behaved nicely with the state governor. Sometimes he can be tricky…
Ya, He behaved nicely… We controlled it with Android Slider, so that it can’t get uncontrolled.
Nice! One head piece, a big piece to print with lots of support. 🙂
Bravo et Welcome!
Great! Thanks for sharing your pictures
Hello, Thanks for posting your progress! It’s very interesting. I watched your video and realized how inconvenient it was to re print the LowArmSide for to fit the square potentiometer. Therefore I made an update to have both, round and square fitting on the same file.
I have a few recommandations: 1-You need to modify the number…[Read more]
thanks for useful help and comments.
Gael Langevin posted a new activity comment 3 years, 9 months ago
Hello, the version of batteryHolder you have is not the latest. The latest versin has a gap to give more space. See in the gallery: http://inmoov.fr/wp-content/uploads/stl/Back/BatteryHolderLeftV5.stl http://inmoov.fr/wp-content/uploads/stl/Back/BatteryHolderRightV5.stl You will need to reprint or to cut off some material from the battery holders.
Ah, ok! Thank you! PS: This robot is realy amazing!
interesting! it reminds me the first version I was using of MyRobotLab, all via python. The training you do is also possible with MRL via the chatbot, somebody in Brazil was doing something similar which might interest you.
is it the \”shake hand\” gesture or did you make something different?
I made my own program in Python for control all servos, I can do any movement and save it, then call any with one word
for example i say “Ari mueve brazo derecho 70 grados” “Ari gira hombroGira derecho 30 grados” “Ari cierra menique derecho 60 grados” etc.. then save “saluda”, then i say “Ari saluda” and he do all movements saved in file “saluda”
Is a trainning, one word with a set of movement
Hello, You need two Nervo Board kits if you plan to use two Arduino Mega. No other pcb is required.
Cool, thanks for posting.
Hello, Very nice demo. 🙂
Hello Juerg, Super it will great to follow your progress!! Nice video by the way. 🙂
Try to see if you can find something similar where you are. Or order from anywhere on Internet.
Hello Gael,
please let us know the original Hardware (Screws/nuts/bolts)which used to build Inmoov .am unable to find
Hello, You can find some information in the “Hardware and BOM” page.
Nice progress and pose for your robot. http://groups.google.com/forum/#!topic/inmoov/Hmg10sVv2l4
Hello, Have a look in the Hardware and BOM page
Hello, I use a trolley and attached InMoov on it. https://s2.lmcdn.fr/multimedia/521401705022/1d14656c352d6/produits/diable-pliable-standers-charge-garantie-100-kg.jpg?$p=hi-w358
Thank you. from where we can buy this ?
Thanks for posting your picture! Nice workspace also.
Thank you so much
Hello, any text editor can do the job. I like to use SublimeText.
Cool gesture!
Thanks.
Hello, Here are three pictures I did a bit in a hurry. If you need more info, let me know. http://inmoov.fr/wp-content/uploads/2019/04/IMG_3891.jpg http://inmoov.fr/wp-content/uploads/2019/04/IMG_3892.jpg http://inmoov.fr/wp-content/uploads/2019/04/IMG_3893.jpg
Gee Markus, we are going to lose you in virtuality.
InMoov says: Where are my legs? Cool progress!
little by little hahaha.
Fantastic! First InMoov I see on a skateboard!
Thank you Gael. Boy, are we having fun …. Thank you again for your inspiring and innovative InMoov!
Hello, yes one mega with one NervoBoard will do the job. It will be called LeftSide Arduino. You will need to trick the pins for the RollNeck though, because normally it is attached to the right side Arduino. You can select a different pin in the config files of head. And also select the left board to be the master for…[Read more]
Gael Langevin posted a new activity comment 3 years, 10 months ago
Hello, The AIML programming is not so complicated to learn but it can be tricky because it communicates between files. Sometimes it takes time to find to which file some code refers to. Basic of AIML is on internet with this for exemple: https://www.tutorialspoint.com/aiml/ There is a small free software which can help you build your AIML (I…[Read more]
Hello, Unfortunately the map is out of function since almost two years. We already got some help from different members but it never got completely resolved. It\’s mainly a problem of creating a new map directly on the InMoov site with the importation of all the previous map Google data.
Cool, 0.57% ? What servo did you set instead? Do you use the Italian configuration for your InMoov in MyRobotLab?
🙂 Well, there was a long list of members waiting for approval. Checking them all today made the number of members increase in a short delay. New members to be approved must have a InMoov picture for their profile picture. (can be anything as long as it’s an InMoov part). It will save me time when approving members. Thanks and welcome to all new…[Read more]
Very, very nice effect! The silicone seems extremely soft, did you add a lot of silicone oil? Is the skin mounted with magnets?
Expressions!
Italian InMoov?
Yes i am italian😆 and my InMoov is 0.57% scale.
Very nice!
Hello, Yes one is enough.
Hello, The Spanish version is not very developed because there isn\’t much help from the community. We would need to get help to improve the AIML files.
Hello Gael, Thank you for your prompt response. I would love to participate and improve the code. I have no experience in programming of AIML but i have some expirience in Python and Java. I would be grateful for any guide that I can you give to collaborate in the improvement of the version of the bot in Spanish. I’ll be bothering you when I…[Read more]
Hello, The AIML programming is not so complicated to learn but it can be tricky because it communicates between files. Sometimes it takes time to find to which file some code refers to. Basic of AIML is on internet with this for exemple: https://www.tutorialspoint.com/aiml/ There is a small free software which can help you build your AIML (I don’t…[Read more]
Hello, Way, WAY above those numbers! The current estimation 16/03/19 is above a thousand built partly complete. We have no idea how many complete robot there is. To give you an exemple, I was recently visiting a school, where they have 3 complete (with legs) InMoov. They never posted pictures or videos of their robots… The 1000 clones is based…[Read more]
Gael Langevin posted a new activity comment 4 years ago
Oh hey you could meet these guys: https://i.avoz.es/sc/rtP8kAs8beZ6sTjcNFLC4j2eRqo=/x/2017/04/10/0012_201704VA10C3F1jpg/Foto/VA10C3F1.jpg
I am glad the Italian version is finally getting used! I am currently working on the Portuguese version if anyone is interested. It will be released with Nixie MyRobotLab.
My next step is to put ball bearings in the neck for a smoother movement. Replacing the battery to the pb with a more powerful 14/15 volt lipo with use of switching inverter for 6 volts for servos and 12 volts for other uses.
Study hypothesis for the use of Inmoov movements of a hoverboard with self balance
Hi fellows, Gael how can i acess the portuguese bots that you are developing?
Hello, Here is the Github link for the Potuguese bot files. Note that it is at a very basic level. https://github.com/MyRobotLab/inmoov/tree/develop/InMoov/chatbot/bots/pt-PT
Thank you very much … Greetings “
Nice color matching!
Superbe!
The wig makes the difference! But maybe it\’s you that needs hair. 🙂
Very nice to hear that!
Thank you Gael.
https://www.ebay.ca/itm/DC6V-50A-Switching-Power-Supply-General-Type-300W-DC-6V-Power-Supply-/142852738995?hash=item2142afcfb3
Some models are trying to walk… But it\’s a matter of time. http://myrobotlab.org/content/version-2-legs
Welcome!
Hello, In the version MRL 2693.7, the virtual InMoov cannot move the fingers. I am currently reworking all the 3D files in order to have more potential for the next MRL release. Hopefully the fingers and the eyes will be operational in VinMoov.
Hello, it\’s been almost two years that the map is not working… Some help came to try to fix it, but it is still not resolved unfortunately.
Well the problem is that the owner needs to make it public so that people can pin in, right now the link only allows viewing, or whomever owns it could share it with someone that can share it with new people.
Hmm. I will look into this a little bit I work at a newspaper and will ask the digital editor what we use for things like this, maybe we can get a new one goin while saving all the current info on it. I would be willing to tinker with it.
Hello, I think you have a power issue, if you use the NervoBoard it will solve that. 1- Make sure your Arduino is grounded to the servo AND to the power source(battery) http://inmoov.fr/wp-content/uploads/2013/12/ArduinoPowerSupply1-1024×771.png 2- Make sure you have enough Amps to supply all your servos. 3- If you are using a breedboard for to…[Read more]
Gael Langevin posted a new activity comment 5 years ago
Great Markus! This is a very nice initiative! More explanations and focus on how we could reproduce what you did would be super for the builders!
Oh my! All those fingers! Well you robot is already well advanced. Keep it up!
You are physically younger than I expected! The question now is, will you pose next to your robot or again with a bus the next time we see you? 🙂
Lol,,, next pic will be with Inmoov ,, I’m 35yo in this pic and i just turned 40 –,,, Still look the Same which is kinda weird – ,,lol
Retweeted on our feed, very nice résumé!
Very nice looking robot!
Thanks You Gaël, but all the credit goes to you.
Hello Simon, In the Hardware and BOM page:
Default Hardware Map + BOM
10x extension spring 0.51mm diameter, 1cm length(13/64″x13/16″) You can find boxes on eBay for exemple: https://www.ebay.fr/itm/Neilsen-150-Piece-Spring-Assortment-Various-Metric-Sizes-Storage-Box-8T/371323746282?hash=item56749eb7ea:g:W6MAAOSwqu9VTfb~
Happy New Year Bob!! And keep posting great videos and updates! Your wokshop is really great and spacious and warm, better be because it looks cold outside. 🙂
Thanks Gael. Same to you. Cold outside!!!!!! That day it was a crisp -37 degrees C outside !!!
Thanks Lecagnois!
Hello Damian, you simply didn\’t put the potentiometer on the correct side of the elbow, therefore you have set ElbowShaftGear upside down.
You have to make a choice, either you use an extra servo for thumb or you set the spring tensioner. Both are to be set at the same location. Personaly I was never thrilled about that extra thumb actuation, because the demonstration videos I had seen didn’t convince me. But regardless, you can still attach the servo, there is holes to set three…[Read more]
Thanks Gael, it’s great to have your personal input, this is such an incredible project. I think I’ll take your advice and stick to the original design, I wasn’t happy with the way that thumb joint printed anyway. Do you have any suggestions as to where to source the springs? I’m having a real problem trying to find any. Also, what is their o…[Read more]
Welcome Jim!
Clean and effective!
Yes! Now we are talking about maybe InMoov walking for 2018. First InMoov step was done in 2017, but with legs that couldn\’t really support the body parts.
Amazing color match and face color!
Handy! I had made some but didn\’t post them because they were not very accurate regarding the HS805bb.
i know what you mean,,, it took me a few attempts to get the dimensions correct so when they are 3D Printed the dimensions are correct–,, (that statement sounds kinda weird,,,lol)
Great impulse Markus!
Gael Langevin posted an update 5 years ago
Happy New Year Everyone!! Have a great time and enjoy your family, friends and robots!!
bonne année à toi Gael . et a toute la communauté d INMOOV.
Gael Langevin posted a new activity comment 5 years, 1 month ago
Kinect Tutorial done:
Howto Kinect
Hello John, These parts normaly don’t need refining, I checked again the models and I have a gap between the parts of about a 1mm which lets them assemble correctly. http://inmoov.fr/wp-content/uploads/2017/12/Face-connection.png The piece you have doesn’t have the nut holder, so I suspect its an older…[Read more]
Hello, Check the \”Hardware and BOM\” page in the \”Build yours\” tab.
La configuration de la prise en charge de la Kinect s’effectue dans les scripts de config. InMoov/config/service_E_OpenNI.config.default isKinectActivated=True Afin que votre systeme utilise le micro de la kinect et non celui de l’ordinateur, il faut modifier vos paramètres dans Gestionnaire de Périphérique de Window…[Read more]
Thanks Perry, I should still make a short tutorial for to use the Kinect, but I didn\’t get the time yet.
Well, I am waiting for some components from AliExpress which need to be tested before release. Just for info this is already my third knee design, which all three were pretty different. R&D takes a long time and my problem is that I don\’t only work on the legs.
beautiful advanced gael.
Thanks Mindless!
Hello Hugues, I am the only one updating the files on InMoov site, it’s a LOT of work to maintain, I can tell you that, and I do that only to please others for free… The parts you are talking about has been updated in 2015. I discovered that I forgot to update the ZIP file which contains the version LowerBackV2 file. A while ago I wanted to…[Read more]
Hi. I can understand the difficulty of maintaining files. I have been involved in R2D2 Hobby building and designing and providing open source files. Keeping revisions up to date is a real work in itself. I will definitely only follow the Gallery from this point. Definitely a good idea to remove the zip files.
Great work though.
Just out of…[Read more]
Hay Hughes,,, It would be Wise to Really Study the Inmoov Project before Stating it again,,, this the most Complicated and Expensive Project available for 3Der’s & Modders ,,,,, And Good Hands On Mechanical & Software Design Experience a Must Have Pre-Request,,,, there’s a lot of Bugs that still have to worked out so re-printing parts is Nor…[Read more]
Gael Langevin posted an update 5 years, 1 month ago
Hello InMoov builders! Here is a view of the knee actuation. This is done via MyRobotLab with the DIY Servo service. More to come with the Ankle and Thigh actuation.
Awesome,,, It’s great to see your R&D work on his mechanical operation for this section–,,,
This is awesome, How long before we start to see the files for the different parts? I am very interested in the files for the feet and ankle drive system.
Well, I am waiting for some components from AliExpress which need to be tested before release. Just for info this is already my third knee design, which all three were pretty different. R&D takes a long time and my problem is that I don’t only work on the legs.
With the HOWTO, it\’s even better. 😉
I didn’t realize you had a tutorial page up for that. You’re site is coming along nicely.
Thanks Perry, I should still make a short tutorial for to use the Kinect, but I didn’t get the time yet.
Nice! Added to the derivatives:
InMoov parts and derivatives
Hey yes, that\’s the privilege to use beta version! You should see the boxe of beta pieces that are unused in my workshop… Anyway the motorized legs will require to almost reprint it all. 🙂
Yes, this must happen to many people. I see some builders still printing the original hand that I posted in 2011 on Thingiverse, instead of the updated version from the site.
Darn, I must have printed the early versions. I’m all glued up too. One of the pains of being one of the first printers. Oh well, mine seem to align a bit better and since I have a color transition it is not noticeable.
Hey yes, that’s the privilege to use beta version! You should see the boxe of beta pieces that are unused in my workshop… Anyway the motorized legs will require to almost reprint it all. 🙂
Okay, It\’s nice if the robot is seen in Korea!
@Dominique, Cela doit être avec LocalSpeech si c\’est possible.
Super, donc avec LocalSpeech les voix Voxygen peuvent être prise en charge. Je n\’ai jamais tenté cette direction. Merci à Anthony et Dominique pour cette intégration dans MRL.
oui sa marche si les utilisateur achète la voix
Cool, when InMoov does Shakespear! Lots of phrases to add in the script.
Hello Mindless, You must have the first version, this was an issue that was reported a few days after I posted the parts. I have modified since then. ( I had mixed a piece of the motorized legs with the non motorized when uploading) ThighLowRightV3.stl ThighLowLeftV3.stl
No worries,,, I’ll download the new V3 Parts,,,, I really should of checked that out first but it didn’t even occur to me to have a look for a updated part,,,, anyway cheers mate–,,
It\’s very interesting to see how the legs were mapped based on my 3D scan of full InMoov. Great work with the leg mecanism! Someday InMoov will walk!
Thanks for posting Mindless!
Non les voix de Voxygene ne sont pas prise en charge, à moins que celle-ci puissent être utilisé par LocalSpeech. Par contre, il y a d’autre voix disponible pour le Français qui peuvent-être paramétrées directement dans les configs, mais il faut un compte gratuit comme par exemple avec VoiceRss ou Polly. Autre exemple avec les voix de votre…[Read more]
d’accord car jai acheté la voix de eva spécialement pour cela dommage merci quand meme
Tu peux aussi utiliser MicrosoftSpeech avec une voix BestOfVox
comment proceder Dominique ?
@Dominique, Cela doit être avec LocalSpeech si c’est possible.
Nice legs! I am kidding… Good progress, what is your plan about that TV drama CF? Can you tell me more about it?
Super, I love to see these progress!
Ehi! 🙂 In French it\’s Chuuut. Chut in French means Hush or be quiet. Some builders were complaining that the Startup_Sound was scaring them when they were working on their InMoov during the night. So I told InMoov to be quiet.
All parts list and BOM page:
Hi what is the recommended main servo for the head. I am trying to work out the size to get so I can start fitting it together. Kind Regards Ian- John Hughes (@templar66) December 10, 2017
2x Hitec HS805BB HEAD 4 AXIS 1x servos HK15298B JAW MECHANISM 2x Servo DS929hvCorona or similar EYE MECHANISM
Nice and smooth.
Une fois l\’installation de MRL effectuée: Ouvrir avec un editeur de texte: InMoov/config/_InMoov.config.default Modifier: [TTS] MyLanguage=fr ; en,fr,es,de,nl,ru,hi MyvoiceTTS=MarySpeech ; you can use MarySpeech,Polly,VoiceRss,LocalSpeech,IndianTts MyvoiceType=upmc-pierre-hsmm
Enregistrer, redémarrez en double cliquant sur START_INMOOV.bat
merci sympas
Waoo cool!
Hello, It sounds like you have tangled the tendons somewhere. Inside the finger itself perhaps. This affects the ability to move a finger, because when one tendon tries to pull it also stops the other tendon to release. And yes each finger needs it\’s own min and max position.
Hello, On your picture you are giving an angle between thos two parts, but if you align the holes there shouldn\’t be any gap. (Or almost no gap, it depends on the quality of your print) See the image: http://inmoov.fr/wp-content/uploads/2017/12/Sans-titre.png
Ah, now InMoov has a legging! Nice work shop by the way!
Wow,,,, that’s Bright , that Reddish/Maroon colour almost looks likes its Anodized Alloy in the Pic– very cool,,, never would of though that colour would look so good on Inmoov–
Nice color mix!
Hey, rock it!!
Real cool !
Hello, Your printer slicer software needs a better calibration. It\’s slightly over extruding.
Gael Langevin posted a new activity comment 5 years, 2 months ago
It\’s important to have screws that go all the way through the ball because they are much too fragile. I had to glue them with acetone a few times already due to travelling. If I would do something in redesigning this, I would over dimension those balls and their axes.
Yep,, I agree Mr Gael- ,, I was playing around with them last night and the Endballs are 12mm Día with a 7mm Día shaft which is just too small– –
I’ll start by printing a series a of Endballs and shafts at different sizes – but I think 18mm or 20mm will be a good size but won’t know for sure until I start printing tonight ,, I know a few tricks…[Read more]
Nice prints! As you know I print InMoov in ABS, and try to print everything without support. I print the worm gear and bicep piston parts without support. I never run fans in my printer to cool down the parts, but I have set an aquarium pump with a tiny tube that travels all the way to the printing head, which then blows precisely an air stream…[Read more]
Ha ,,Ha,, and I thought I was the only one crazy enough to have a Air Pump from a Fish Tank on a Printer (But my son wasn’t impressed that I killed all the fish) – but anyway,,, that was the only way I found to get good Print in ABS too—,, the good thing about using PLA+ is it forces me to design without gluing to be an option which is chall…[Read more]
Hello John, I agree it\’s better to add electronics as you built the head.
Video Head
The eye mechanism requires only two servo and the price for these servo is much lower than $60. Eye tutorial:
Eye Mechanism
Servo DS929HV for the eye average price is: €5.78 (Hobbyking)
Acapulco, you are going to have legs moving i a short time! Thanks for posting!
Always great to see a father and son working on a project together!
Yeah huge printer indeed!!
Great prints and build Perry!
Super looking robots!
Hello, To run your kinect with MyRobotLab, you need to set it in the config files. The Nervo Board doesn’t take control of the kinect, it’s the software MyRobotLab that will take over. 1-Install MRL by following this tutorial:
Hi I am obviously having trouble negotiating around the site. I can find printing the parts but I am having trouble finding tutorials or step by steps on building the parts. I want to get the black screws to connect the eye piece to the upper mouth. What type of screws do I need and where would there be a step by step guide to construction be?I…[Read more]– John Hughes (@templar66) November 22, 2017
2-Configure the Kinect config in your InMoov/config…[Read more]
Hello, Your issue lays in the main config, you need to modify Virtual to LeftSide or Full if you have both Arduino connected.. https://github.com/MyRobotLab/inmoov/blob/master/InMoov/config/_InMoov.config.default
[MAIN] ScriptType=Full
For more information on configuration you can see this…[Read more]
Hi Gael, i sent you a privaye mail last week , i need to speak with you, is posible? Thanks Gael.
In the neck tutorial you can find this video which is usefull for to assemble the head:
Hi So I am slowly progressing with the 3d printing of the head parts, and I can see that there is a tutorial for putting the eye mech together and for mounting the jaw. Are there other pictorial tutorials on how to build the whole head up? Kind Regards Ian- John Hughes (@templar66) December 1, 2017
